Specifications
keyboard 88 weighted wood keys, AWA grand III action
polyphony 64 notes
sound generation Harmonic Imaging Stereo technology
internal sounds concert grand, studio grand, mellow grand, modern piano, rock piano; e.piano 1 (Tine), e.piano 2 (FM Type), e.piano 3 (Reed); Organ 1 (B-Type), Organ 2 (jazz-Type); Clavi, Vibraphone, Strings, choir, bass 1 (Wood), bass 2 (Electric)
reverb types Plate, reverb 1, reverb 2, stage 1, stage 2, room 1, room 2
effect types Choirus 1, Choirus 2, Choirus 3, Flanger 1, Flanger 2, ensemble, Celeste, delay 1, Delay2, Auto pan, tremolo, Phaser 1, Phaser2, rotary 1, rotary 2, Auto Wah, Exciter, Enhancer, Overdrive, Distortion, SympRes
display 16 characters x 2; LCD with background light
controls pitch bend wheel, modulation wheel, master volume, zone volume (x4), zone Edit Choice (x4), zone on/off (x4), real time edit control (x4), control mode switch (x4), EFX on/off, reverb on/off, menu up, menu down (Link mode), value up, value down, sound mode, Set up mode, (system mode), sound /Set up Choice (8×2), store, transpose, split
back side 6,3mm jacks for line out (L/Mono,R); XLR Out (L/R); headphone, damper/soft pedal, foot switch (assignable), expression (assignable), MIDI In / Out / Thru; AC in, power switch on/off
parameters for internal zones zone hi, zone lo, velocity switch (Off, Soft, Loud), velocity switch level, velocity Sensitivity, damper (on/off), FSW (on/off), EXP (on/off), mod wheel (on/off), bender (on/off), pan, transpose (±36), Fine Tuning, bender range (0-7), Virtual Voicing (mellow, Bright, Dynamic, normal)
parameters for external MIDI zones zone hi, zone lo, velocity switch (Off, Soft, Loud), velocity switch level, velocity Sensitivity, damper (on/off), FSW (on/off), EXP (on/off), mod wheel (on/off), bender (on/off), pan, transpose (±36), Fine Tuning, bender range (0-12), Knobs A-D (on/off/CC#), TX Channel, TX Program, TX Bank; Attack, Decay, Release, Cutoff
system parameters Master Tuning, system Channel, Footswitch CC#, expression CC#, Touch Curve normal, light, light+, heavy, heavy+, Off), LCD Contrast, RCV CH 1-16 on/off
dimensions 1466 x 442 x 178 (mm)
weight 33 kg
accessories F-2r damper+soft pedal included
